Mtg 6/25: Wed-20-Sep-2023

Outline for Today

Wiki

Link to the UR Courses wiki page for this meeting

Media

Transcript

Audio Transcript

  • How's everyone doing today? Better
  • How's everyone doing today
  • felt cold when I left the house this morning but now it's not bad I
  • go to bed weather alert on my phone day before yesterday that temperature the temperatures gonna drop and I really wasn't expecting it to go down to three while we were down three yesterday
  • dad was like 30
  • Okay
  • Okay, so we're
  • gonna continue on chapter two in the theme of graphics programming today
  • actually a little bit cooler in here.
  • So
  • please remember to record your attendance. I'm not going to from now on I'm not going to really remind you or good morning or marquee present after the fact
  • okay
  • so there's a comment about summarizing what we've discussed in the meeting. So I'm going to try and do that
  • so I'm
  • so I've added a heading for that purpose. So today we're going to look at the basic structure of what the WebGL programs and we're going to look at 2d and 3d, Sir Pinsky triangles tetrahedrons.
  • So this is kind of this isn't a great picture, but this is what I have on the web
  • I should have a bigger maybe this is done in 1990.
  • What's the ray tracing program so you can see reflections so you can see this weird green surface that's very polished because we have a reflection and shadows and we have a perspective you
  • the dots so the tetrahedron
  • has four triangles put together
  • so there's two basic triangles a bit the base is a triangle. And there's one, two and three on the other side.
  • So that's what circusy gasket looks like in 3d.
  • So, over the semester, we'll
  • be adding we'll be able to make more complex images like this. Today, we're not going to consider all the bells and whistles that are in that image.
  • So I've
  • renamed these files, so they were gasket one through four in the interactive computer graphics.com website.
  • And then Sue is
  • So that's one we looked at last day
  • so
  • I just want to mention about the coordinates that the world coordinates that we're dealing with. As part of the pipeline
  • So
  • So remember we define these vertices at vertices as minus one minus one one minus one and 01
  • So we have
  • these two coordinate systems
  • and
  • what's important is the relative position of the camera and our
  • gasket in this case.
  • So we're not dealing
  • we have
  • we're using love defaults here for the viewing we'll get into more details about that. But the clipping coordinates what's inside those coordinates will be displayed
  • so I'm going to try editing some code
  • I didn't rehearse this. So
  • we'll see how that goes.
  • Okay.
  • So if I'm changing one vertex
  • to be not minus one to minus two.
  • That's going to stretch out the triangle
  • and it should also be partially obscured.
  • That make sense
  • what we're seeing here
  • so by default we're looking to regional that we're looking at display is minus one to plus one minus one to plus one. Originally, the triangle was defined in those coordinates. So we saw the whole thing
  • now it's not so we see the the change in the shape of the triangle and also part of it is clipped
  • so it's
  • not part of the image.
  • So here's an example where
  • so we've changed the coordinates so there contained within the clipping so we see the whole thing
  • and I'm gonna change this back before I wonder what happened to it.
  • Up Okay, any other
  • changes to test on this one
  • so just to go through the JavaScript here so we
  • have
  • JL is going to be it's going to hold the context for the web. GL version two. And we use it not just in a net but in render. So that's why it's
  • it's defined in that scope
  • and then we have an array for the positions so we're getting the canvas from the HTML file
  • and then regenerating the data
  • so we're going to set up a number of positions. So the number of points is going to be 500,000.
  • So here I've
  • set the starting point as one of the vertices.
  • Storing
  • that initial point in the array of positions
  • and we're doing the transformation and adding subsequent points. To the array of positions. So that's the data
  • so under setting up
  • the web GL so viewport is
  • is taking the
  • clip coordinates minus one plus one minus one two plus one and mapping it into
  • the screen our campus.
  • Clear color we're setting it to be white
  • so I went
  • and added a bit more documentation
  • to this example.
  • So when array buffer
  • means that the buffer contains vertex attributes such as vertex coordinates, texture coordinate data or vertex color data.
  • So we
  • are creating a vertex or an array buffer getting the ID
  • and
  • the usage of the buffer is static draw, which means that we generate the points once and draw them multiple times.
  • So whenever
  • we're getting the position location
  • some
  • in the documentation sometimes it says index and also refers to location so, this is the way they've done it in the
  • in the sample code so, I kept that naming
  • So, the program has the shaders. So, we're finding
  • variable from the shader.
  • And then we're enabling it. So we're making that connection with the shader and then in the render.
  • For clearing to wait and then drying the points drying the contents of the array of the buffer as points.
  • So here's the
  • the variable in the shader
  • so we're looking up and making the connection to
  • let's try
  • let's try this with a bigger point. Size
  • let's go bigger still
  • okay
  • now let's look at
  • evening let me show up
  • right
  • so we're doing the same kinds of things here
  • so
  • now we start with a triangle with the vertices as we had them before
  • we have a function divide triangle. So we take the three vertices and then
  • we pass a number of times to subdivide.
  • Let's do
  • it three which is a little bit easier to see, maybe
  • you're all just like I wanted to take one
  • so dividing the triangle
  • I feel like I could improve this code a little bit
  • so we're dividing the triangle. So
  • count is the number of times to subdivide.
  • So if our count is zero as then we've reached the end and we're going to create a triangle
  • never passing the
  • the vertices of a triangle and then the work
  • to try and go function will push the coordinates into the position array
  • so if we're not finished subdividing.
  • Divide the triangle
  • make three smaller triangles reduce the count and then we divide each of those three triangles until we get to the lower limit of recursion.
  • So this time instead of points we're drawing triangles
  • so we're
  • doing the same things in terms of setting up the buffer to hold the positions. The only difference is we're interpreting the contents of the buffer as triangles
  • and we're doing the red color
  • so everything is colored red, so there's no
  • just a very simple fragment shader here
  • okay.
  • So let's look at
  • does that look like a 3d object?
  • Okay, let's look at
  • what we see colors are changing here
  • let's look at the JavaScript first.
  • So we have the same
  • the same setup we get the graphics context
  • so I notice
  • that they're using different vertices then. Then the recursive 3d example.
  • Let me update
  • Does that look more?
  • More interesting.
  • Okay. I just
  • so we're doing the same thing we're picking transformations at random based on the vertex or picking a vertex 012 or three and then
  • and then doing the transformation and saving the point
  • so we're one thing that's different here is we're enabling a depth test. So we're keeping track of the positions have pixels of the point so we're drawing
  • we're displaying the nearest points
  • so after covering
  • ones further away, you don't see the ones that are further away. Okay, let's turn that off and see what the difference
  • changed. A bit.
  • So let's look at
  • the shaders. So we have
  • are taking in the position and we're passing out a vertex color.
  • So we're
  • not computing the color based on geometry. We'll see an example of how the color gets
  • assigned.
  • We can do a color buffer with our next example. Here we're doing a computation based on the position
  • fragment shader is just taking the vertex color and passing it to the fragment color or assigning it to the fragment color.
  • So this is a way
  • that we can change colors without using a color buffer, we can
  • just do the computation in the shader.
  • Before we have to leave
  • look worse to 3d Guess
  • so here
  • we're using a color buffer
  • yes thank
  • you have a nice day thank you okay
  • now
  • so use the same
  • coordinates with vertices as
  • as the 3d Chaos game.
  • So, we're doing the same kind of approach instead of dividing a triangle. We're dividing a tetrahedron. So we have four vertices.
  • And then we have a number of times to subdivide so let's change that. From four.
  • That's maybe a little
  • makes the structure a little bit easier to see.
  • So
  • what's different here? We're doing colors.
  • But we're using a color buffer.
  • So we're creating an array buffer
  • so I've
  • used the Canadian spelling of color in the JavaScript file, but got it
  • I use the American spelling kept the American spelling in the shader so that's why I'm looking for a color because that's that's the variable name and the shader.
  • So
  • we have a buffer for colors information and we have a buffer for vertex information.
  • Should we change the
  • colors okay, what instead of red?
  • How will we do yellow
  • and instead of green
  • we can
  • I would say
  • that should be magenta the fourth color is black but we don't see any of the black.
  • Okay
  • so we have triangles and then the color
  • so the tetrahedron
  • with these four vertices is made into four triangles and we're assigning a color to them
  • so,
  • if we've reached the depth of recursion, then we create a tetrahedron which is made up of triangles. Otherwise, we subdivide
  • again
  • so, we're drawing
  • triangles again, for the positions
  • so
  • let's see
  • the free turn off.
  • So
  • if again unexpected results
  • I'm gonna try this once. More
  • change this color to red
  • and let's
  • go think I'll make a difference
  • so does this make sense?
  • So we're drying the front facing triangles
  • so we have the yellow,
  • cyan and magenta but we don't have the sense of a 3d structure because
  • we haven't got
  • we haven't preserved the depth information here
  • so by moving so when it
  • came in is all black or all red
  • the back facing triangle was drawn last
  • so that
  • overrode because because we're not using the depth information and overrode.
  • These triangles which were
  • closer
  • I think that's all you need to say about that. If that makes sense.
  • What we're seeing
  • thought I'd put the assignment yeah
  • so I will I'll get that sorted out.
  • So basically, it's going to be
  • making some changes to the example code and we have
  • discussed already adding some
  • features so I'll get that posted and
  • posted here and linked on your courses shortly after class today
  • I didn't
  • put this into
  • our exam. Or the code examples that I
  • updated
  • here's an example of
  • using a
  • slider
  • so this is the subdivision level
  • very
  • much example of how to use adding some controls in HTML and connecting them to
  • JavaScript
  • Okay, so we've talked
  • about
  • some structures so are using
  • we are using
  • to find colors in the shaders and they are excited for this but you're like well listen to an album like in a row on my drive home like
  • in chaos 3d We did the color based on the shader only. And then in the 3d example we did colors based on a color buffer
  • and we also looked at the
  • using hidden service eliminate removal by keeping track the depth
  • so I'll add some more comments to those those code examples
  • any questions or concerns?
  • I know we're out of time here so
  • if anything comes up, let me know. Post in the question post in the class discussions.
  • So that was
  • a good way to go through things okay. It just occurred to me that anyway
  • I didn't this is the first time I've tried it this way. So I welcome your feedback about things and how to do things more effectively. And
  • so I didn't put it here, but if you want to take a look at chapter three.
  • We'll get into those things next week.
  • Okay, thanks again for today. Have a great Wednesday and a great weekend and I have office hours tomorrow as anyone tried to reach me in office hours and not been able to okay
  • I'm not I'm not always good at turning on the Zoom to try and get me by zoom. But anyway,
  • don't have to be shy about getting a hold of me if you need to. Okay.
  • Have a good rest of your day?
  • Have a good day. Thanks you too. Thanks, you too.
  • This company thanks you too.
  • This company thanks you too.

Responses

What important concept or perspective did you encounter today?

  • Learned about the the 2D gaskets as well as graphics pipeline and also about the camera coordinates and clipping coordinates
  • I learned how to add a slider in Sierpiński Gasket.
  • The most captivating aspect of today's class was hands-on exploration of 3D depictions of Sierpinski Gaskets. What made it particularly intriguing was the ability to alter the camera's position, providing with a dynamic perspective and enhancing our understanding of the subject.
  • I learned about the Graphics pipeline, 2D gasket also learned about the vertex shaders and fragment shaders.
  • The Depth-Buffer and how it is used for detecting obscured surfaces in a 3D space for the Sierpenski Pyramid.

Was there anything today that was difficult to understand?

  • The code for graphics

Was there anything today about which you would like to know more?

  • Would love to know about graphics pipeline.
  • is creating 2D and 3D structure of Sierpiński Gasket using WebGL
  • The triangle for Sierpinski Gasket with 2D slider made me understand more and more clearly. Is there something like 2D slider for the chaos algorithm? I found this one (https://www.youtube.com/shorts/QK2SJo-AxT4) but it only provides a few iterations. What will happen to a very first POINT if we put it in the center of the equilateral triangle?
