Mtg 22/25: Wed-22-Nov-2023

Outline for Today

Wiki

Link to the UR Courses wiki page for this meeting

Media

Transcript

Audio Transcript

Happy Wednesday.
So I had Sorry, do you have a question?
I was confused because previous assignments had two codes like
two separate. Like samples are like two separate codes and this
time it's just one so I was like, making sure like if it's
just one or like I'm making some mistake or not.
Now I was thinking about making it easier. Thank you.
Sara, you You said earlier that there might be a chance that you
can give us a day or two and assignment number three by you
were posting it because we have a project assignments coming in
this week, as well. So, you consider
Yes. You mean in your mobile computing class do you have a
project and assign Yes, project.
Presentation is not not today, but actually
the final exams the projects of the presentation, okay.
Morning
Monday.
27th Right. I think that's the right day. Monday is the 27th.
Yes, okay. Thank you.
Okay, does that sound like a plan?
Morning
Day
screen down
so, one Examples from the text is the
I don't remember what he called it. I don't think it's cube
elfa. Pardon me, I said it's a deconstructed cube. Yes. So the
issue is
so we talked about translucent surfaces the other day.
So the idea was to draw opaque polygons with a depth buffer. So
we're going to enable depth testing. We're going to write
the depth buffer for opaque polygons. And then we're going
to use the depth buffer information, but not write to
it. Read Only to render the translucent polygons and we're
going to do them in order for this to nearest.
So I deconstructed the cube, as Karen says so that I could you
can easily order to Polygons from back to front.
And then I'm every time I'm rendering, move them around a
bit so you can see some different effects.
So now the yellow and the cyan are opaque.
So what does that look like? code
so I'm passing in. So I have vertex attribute for the
position and for the color and I have a model view and a
projection matrix. So I'm determining position by
multiplying the input vertex position by the modelview matrix
and the projection matrix
and then for a fragment shader just passing through the vertex
color
and saying the fragment color
so here are the coordinates of the of the faces. So they go
from minus point five minus point five to plus point five
plus point five. So you're squares around the origin and,
and then I'm saying this Zed value to be different. So I'm
starting out, this is the furthest 16543 to one
and here I'm saying the face colors so I can, you can see
that blue and green. have alpha point five and red and magenta
have alpha point five.
And then I'm saying the projection so I'm going near
zero far is 10.
Left and right bottom and top. And then I'm specifying the
viewing transfermate viewing make viewing parameters so the
eye point is at minus one and Zed looking at the origin with
the y positive y axis is up.
So here we're generating the data. Setting the viewport
enabling depth test
your we have the color buffer and the vertex buffer. And then
we're setting up the location for the projection and the view
model view matrix made those matrices so when render
we clear this the color and the depth set the projection matrix
so we turn on depth mask true that means we're writing to the
depth
and we disable blending
I'm not sure that's strictly necessary but
I had
better safe than sorry. I think it's good practice to do that.
So then, here I have the indices of the opaque polygons. So I'm
going through the list and then I'm creating the modelview
matrix. I started by applying a random rotation then a random
translation and then I multiply that by the look the viewing
transformation so that gives the model view transformation
and so I'm drawing each face separately
and this is giving the offset into the coordinate array and
redrawing six vertices, so two triangles with each. So, other
words a square with each call to draw arrays. And then when we
finish that then we go and draw the translucent spheres. Sphere
squares pardon me. So we turn off writing to the depth buffer.
We're still using it. We're just not adding information to it.
Enable blend. And here's a blend function
so the source is the fragment shader and the destination is
the frame buffer. So that's what we're blending
so we're doing the same kind of setup where we're doing a random
rotation, then a random translation. Then multiplying by
two look at the viewing transformation so.
So we're drawing
each track each square separately from the back to the
front.
So then I'm waiting five seconds, and then we're starting
again. And here's just the code to put the vertex data together
for the triangles. In the squares.
That makes sense. So the thing that caused me a lot of grief
this time
Yeah.
Was the text
US
undefined
because if we don't
I'm not gonna mess with it.
So that didn't come up as an error
at runtime, it did. No, really not even at runtime
so with the depth mask, not so I also by extension I wrote in
gmail dot true so having those two undefined values, messed it
up. And that was the problem. So I have to report that to the
textbook authors.
Anyway, so I'll have I'll have this version published. And I'll
give you a link to it
Okay, so the other one I wanted to show you is.
So what we're doing here is creating a texture in an off
screen buffer and we have a lower resolution version here.
So we can adjust that
example the text was incomplete because it talked about setting
up a render buffer but it didn't use it. So I've used it here. So
this is the way when we do the assignment to buffers. In our
earlier examples where we say bind, create a buffer and bind
it for vertices and colors. If we want to do that for an off
screen frame buffer object, we create a render buffer and then
we attach the render buffer to the frame buffer. And what we
need here is something to start depth because we it's hard to
tell me but there are two triangles one poking through the
other one.
Okay so let's look at
so vertex shader one is just take the position as passed.
Setting the position variable in vertex shader to is taking the
position but we're also using texture coordinates so fragment
shader one
I've changed it from the original to accept a color as it
is a uniform color and so we're setting that to be the fragment
color so that's it that's fragment shader one and fragment
shader two is
assigned the fragment color based on accessing the texture
map. So, fragment shader one are the vertex shader one and
fragment shader one are creating the texture fragment vertex
shader two and fragment shader two are using the texture
okay so
so we're setting we're only using one texture register so we
make that set that to be the active texture create an empty
texture
and restoring RGB, a RGB and alpha and save bytes. So that's
what we're and we're defining it to be a text size
now we're setting some parameters for the texture. So
we allocate a frame buffer object so this is an off screen.
Pleased to render the texture so we bind the frame so we're going
to after we've created the buffer frame buffer, we're going
to use it and then we attach the color buffer and we're going
and for the color we're using our texture, so we're going to
first rate into that texture and then we're going to use it
later. So then this is a way to get the depth buffer set up. So
we create a render buffer. We bind a render buffer to it to
the desk buffer we just created
and then
are setting up the storage for it. So we're making it the same
size of the texture
and here we're attaching
so here earlier we did the color frame buffer texture here. Here
we're doing frame buffer render buffer. So we're attaching to
the frame buffer, a dense attachment
so we're saying this is going to be used as the depth buffer
so because we're doing the depth buffer, we're setting up the
format of the data so we're storing data so we're setting up
the storage to be
for the depths, so this is the way to do that. That constant
so I mean you have more distributed names here. So use
triangle text, create triangle textures, and use triangle
textures. So using create using the first term to create the
texture enable dev test
so here we're setting color for the first triangle to be red
ish. And then the second triangle we're setting up to be
greenish.
So we're jamming the texture and then we're switching from the
frame buffer object to the screen
set the texture and then we render and we're drying the
background square with the texture.
See if we can generate a higher resolution
hello
so we can generate a very high resolution texture. So when it
when we sat lit with the second fragment shader
we have an excess of information here so the result is
a very very sharp image
let's go back to a lower resolution version.
Does that make sense?
So we need to specify
we have to dress for everything right
that means
geography camera.
Staring at stuff starting that would be
so with one are staring so we're staring at arrays of numbers is
not conducive. To.
Smelt up front
all right laserLine
that's not a word
maybe there's not two genes anyway
so
I know looking at so they have a teapot. model in the chapter
nine code there's some errors in it.
It's staring at the numbers not conclusive.
conduce
in brackets as
spelling
let me just let me check my spelling. Here. It is great. Oh
okay
she's added that word there
looks worse
okay
so we want to be able to so we think about the strategy for
modeling something then we want to think about we want to
include a cube we don't
necessarily want to deal with just the cube vertices and then
make that up. So it's better to have a cube object. For example
and then so I want to go through the
Okay, so we've defined two different cubes and we've
positioned them and are doing the rotation
Okay, so let's look at how that's defined
so you're redoing your rotation in the vertex shader.
So it's just a matter of rotation
so we've lived the transformation transformations
to position the Q's in the in the JavaScript code. So let's
look at that now.
So I started adding a third cube. So we'll try to complete
that in a minute
so we have
the color buffer vertex buffer event listeners then further
so we're just drawing all the triangles here
right so let's look at how the cube is defined.
So we're setting up the vertices based on the size. And if it's
not, if it's not specified we set the size to be point five.
Otherwise, if size is specified we said to be half the size. So
the idea is we get a if we don't specify a size we get a unit
cube centered around the origin. And if we do specify a size then
we're specifying the size of the face so we divide by two so we
get a cube around the origin
and we get the face normals and indices. So this is how we're
getting
specifying how to use the vertices and creating a face
vertex colors. So these are all opaque
so this is how we're doing. We're specifying the coordinates
of the
so you can see them how they correspond here to so the first
cube that first face is 1032 and 103321. So those are the way
we're specifying the triangles for the cube faces.
Here are the texture coordinates.
So what we're doing here is applying the modeling
transformations directly to the to the cube vertices so
so that's why we don't have to.
Again, in my elfa example earlier, we did the modeling
transformations separately from the square the squares that are
being drawn. So here it would be if we use this approach then we
could specify the square and the cornice should be changed to
reflect the modeling transformations you've applied
Okay, so that's so we're getting the data set up for the for the
cube this way
so let's add our third
cube
aside from your lab to two cubes, let's see if we can
See if I can
Too far away
okay
so let's
listen advantage of that. Kind of approach.
So looking at the cube data so we've separated functionality
from our Java main JavaScript program. So to see it's only
105 104 lines long. So it's pretty straightforward so we've
managed to hide some complexity what are we so the maybe that's
an advantage.
So if I want to do 1000 cubes in this approach
so I'm getting 1000 calls copies of the cube data.js data
structure so that's not not efficient
so we're also cementing
primitives in, in space, so we're not
so right, we're initializing coordinates there instead of so
you if you want to change the date change the transformations
in the model to animate that might be a problem.
So there is.
me show you the teapot. Instance.
is So here's the problem that I can see.
Collection No, it's not so bad
so I read as I did some reading it was a teapot and originally
it didn't have a bottom. So the bottom data has been added
so the nice thing about
so to be more efficient
not looking at the right file
so instead of copying data and having that inefficiency, we can
draw instance
we can draw arrays instance. So we have one set of data that we
can
got pretty multiple versions from the same model. So that
that helps us to manage complexity make the code more
readable as well.
Okay, so
we've talked a little bit about modeling here. So we'll look at
how to deal with the robot arm and figured out HTML file next
next day. And then that's Monday, then Wednesday and
Monday. The next week. Need to look at the example and current
requested some review material on the course
so we have just three more sessions
yeah Time flies when you're having fun. Anyway, any
questions or concerns?
I'll see if I can find that problem with the data okay. So
thank you very much for today. Have a good weekend. And so have
the due date for an assignment three on Monday at one minute to
midnight. Okay and good luck with your your final slash
project in your other class
Okay, take care everyone.
My name
is be waiting for somebody to come up with
is be waiting for somebody to come up with

Responses

What important concept or perspective did you encounter today?

The most important thing that I learned in today's class was when we started chapter 9 which is all about modelling. In modelling we actually need to tell everything about the scene. We need to define material, geometry, lights ,cameras etc in order to render something that we want on the screen.
Today the assignment was discussed in the class. The dedline was pushed to monday and code was demonstrated.

Was there anything today that was difficult to understand?

is to render gemoetry, lights for a multiple canvas at same time.
Whole modelling was difficult to understand as I was late in the class

Site built: 2025-05-06 13:52 -0600 • Give feedback about page
